Peter electronic VB 230-6 L - 10 Technical Data

12 VB230/400-6/25/30L (LP)
10. Technical data
Type designation VB 230-6
L (LP)
VB 230-
25 L (LP)
VB 230-
30 L (LP)
VB 400-6
L (LP)
VB 400-
25 L (LP)
VB 400-
30 L (LP)
Mains voltage
according to DIN EN
50160 (IEC 38)
220/240V ±10% 50/60Hz 380/415V ±10% 50/60Hz
Power draw of electro-
nics
3 VA
Recommended for
rated motor currents
0.3...3A 2...12.5A 2...15A 0.3...3A 2...12.5A 2...15A
Recommended for
rated motor currents
on IE3 Motors
0.3...2A 2...9A 2...12A 0.3...2A 2...9A 2...12A
Rated device current 6A 25A 30A 6A 25A 30A
c.d.f. at max. braking
current
60% 8% 5% 60% 8% 5%
I²t -value of power
semiconductors
310 A²s 1250 A²s 1350 A²s 310 A²s 1250 A²s 1350 A²s
Braking voltage 0 ... 110VDC 0 ... 220VDC
max. Braking time 12s
Contact rating of out-
put relays
3A/250V AC 3A/24VDC
Delay time for reduc-
tion of residual e.m.f.
self-optimizing 0.2 ... 2s
max. Cross-sectional
area for connection
- Enclosed version (w.
housing):
- Circuit-board ver-
sion:
2 x 2.5mm² per terminal
FASTON connector 6.3 x 0.8mm
