Peter electronic VB 230-6 L - Page 21

20 VB230/400-6/25/30L (LP)
Table 3
t
B
= Braking time, Cycle time = Braking time + Non-braking time
Cyclicdurationfactor
r
·
c
·
d
·
f
·
()
t
B
Cycletime
----------------------------
100×=
Load curve for VB 400-6 L (LP)
0
10
20
30
40
50
60
70
80
90
100
0 102030405060708090100
Cyclic duration factor in %
Permissible max. braking current in % of the rated device current
