Preventive Maintenance Air System
Model 330 PB1318 3/01
– 171 –
To remove the air filter:
1. Remove the two thumb screws.
2. Remove air cleaner service cover.
3. Remove the filter element.
4. Clean out the inside of the air cleaner body and outlet
tube with a dry rag.
To install air cleaner element:
1. Slide air cleaner element into housing.
2. Install air cleaner end cap.
3. Install thumbscrews around air cleaner housing end cap.
NOTE: The air cleaner is internally sealed by a
radial seal around Inlet tube of air cleaner element.
For further information on servicing the air cleaner,
see the Medium Duty Maintenance Manual.
Air Cleaner - Filter Element
COVER
FILTER ELEMENT
00455B
