Start–Up Operating Instructions
– 16 –
PB1318 3/01 Model 330
DASH INSTRUMENT PANEL
1 Headlight 6 Oil Pressure 11 Voltmeter (option)
2 Clearance Lights 7 Water Temperature 12 Air Pressure
3 Windshield Washer/Wiper 8 Speedometer 13 Transmission Temperature (option)
4 Panel Lights 9 Air Cleaner Restriction/Filter (option) 14 Warning Lamp Cluster
5 Tachometer 10 Fuel 15 Ignition Switch
02599A
02595-1A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
