TouchScreens

Warnings

Pressthewarningicononthescreen.

Thiswilldisplayanyvehiclesystem

thatisoutofspecication.Refer

tothevehicleoperatormanualfor

descriptionsofthewarningicons.

Hybrid

PresstheHybridicon.Thiswilllaunch

theHybridmonitoringenvironment.

WhenintheHybridmonitoring

environment,thebottombarmenu

shallbemaintained.TheHybrid

screenshavenotouchscreen

functionalityorinteraction.Onlythe

bottombarwillmaintainthetouch

control.

HybridMonitoringScreen

PleaserefertotheHybridOperator’s

ManualSupplementformoredetails

aboutthehybriddisplay.

DiagnosticMessages

DiagnosticMessageHomeScreen

Thetruckdiagnosticscreenwilldisplay

activemessagesfromthefollowing

systems:

•Engine

•EngineAftertreatmentSystem

•Transmission

•InstrumentationSystem

•Anti-LockBrakingSystem(ABS)
