petMAP graphic - Page 10

9
Systolic/Diastolic
(MAP)
Cuff pressure
(yellow)
Power ON
LED
Cuff pressure scale
& manometer
(Determination descriptor codes - used by remote support)
Low battery LED
Low gain channel
(magenta)
High gain channel
(green)
Species & cuff
site optimization
Heart rate
Measurement Page
Graphic Results Page
Tabular Results Page
NSV Values for systolic,
diastolic, heart rate and
(MAP)
Session’s values plotted
with elapsed time
Session’s Results
Column 1: Approx. time (min)
since Power ON
Column 2: Systolic/diastolic
Column 3: (MAP)
Column 4: heart rate
