Pfaff 3371-1 series User Manual

Setting up
28
Fig. 9 - 04
9.04 Removing / replacing the bobbin case
Switch off the machine.
Danger of injury if the machine
starts accidentally!
Removing the bobbin case
Open the hook cover
Pull out latch 1
Remove bobbin case 2
Replacing the bobbin case
Push bobbin case 2 into the bobbin case
base until you feel it click into place
Close the hook cover.
●
●
●
●
●
1
2
9.05 Threading the bobbin thread / adjusting the bobbin thread tension
Place the bobbin into the bobbin case,
so that this turns in the direction shown
by the arrow when the thread is pulled.
Insert the thread as shown in Fig. 9-05.
Set the thread tension by turning
screw 1.
●
●
●
Fig. 9 - 05
1
