Pfaff 3371-1 series

Input
57
Group
Gruppe
Parameter
Parameter
Description
Bedeutung
Setting
range
Set value
000 021 Thread take-up lever t.d.c. [°]
The position for the t.d.c. thread take-
up lever is entered here. If the func-
tion is executed, the position can be
set by turning the balance wheel. The
access code is necessary for this ad-
justment.
45 - 53 51
022
Thread trimming position (in relati-
on to t.d.c. needle) [°]
The position, at which the thread trim-
ming solenoid is switched on, is ente-
red here. The adjustment is set by tur-
ning the balance wheel. The access
code is necessary for this adjustment.
180 - 253 180
023 Sewing area size X [1/10 mm]
To avoid mechanical collisions, the
sewing area size of the clamp in use
is entered. The control unit checks
the path and, if necessary, issues an
error message.
± 200 -100/ +100
024 Sewing area size Y [1/10 mm]
To avoid mechanical collisions, the
sewing area size of the clamp in use
is entered. The control unit checks the
path and, if necessary, issues an error
message.
± 100 -15/ +15
025
Thread wiper solenoid
operating time [10 ms]
026 Thread wiper solenoid, ratio on-time
to off-time in % (Duty-Cycle)
027 Basic position / loading point = zero
point
ON - OFF OFF
100 101 Software version main processor
The software version of the main pro-
cessor is displayed
0335/xxx
102 Software version sewing drive unit
The software version of the sewing
drive module is displayed.
V.xx
103
Software version control panel
The soft- and hardware version of the
control panel are displayed.
V.xxx/ H.xxx
