Setting up
15
No VAL
760 5
TE
4.05 Setting the stitch counting function for the bobbin thread control
● Switch on the machine.
● Press the TE/Speed key to call up the parameter input function.
● By pressing the corresponding +/- key select the parameter "760".No
● Press the corresponding +/- key to set the number of remaining stitches, which can still
be sewn after recognition by the bobbin thread control function.
The selected value is multiplied by 10* or 200** and the result is the number of stitches.
Example display 5 x 200** = 1000 stitches. The setting depends among other things on
the thread strength.
● If the TE/Speed key is pressed, the value is taken over and the machine changes into the
sewing mode.
The bobbin thread rest counter can only be used, if parameter "660" is set at
value "1" or "2".
* If for parameter 660 the value is "1", the multiplier is 10
** If for parameter 660 the value is "2", the multiplier is 200
VAL
No VAL
101 ON
TE
A
A
