Proper use
4
1 Proper use
With the puller the workpiece is fed continously, which makes it possible to sew to a great
extent without shifting and puckering. The puller’s linear motor enables an individual
clearance space between the needle plate and the puller roller.
All adjustments, such as e.g. puller feed stroke, puller roller clearance etc. are carried out by
altering the parameter values, see Chapter 2.03.03 Selecting and altering parameters.
Any use of these machines which is not approved by the manufacturer shall be
considered as improper use! The manufacturer shall not be liable for any dam-
age arising out of improper use! Proper use shall also be considered to include
compliance with the operation, adjustment, service and repair measures speci-
fied by the manufacturer!
1.01 Using standard presser feet
● With the adapter 1 which belongs to the
accessories, standard presser feed can
also be used
(Ordering number 91-154 790-22).
● Mount adapter 1 as shown in Fig. 1-01.
● Loosen screw 2 and push puller arm 3
back.
● Screw the presser foot onto adapter 1.
● Adjust puller arm 3 so that there is a
clearance of approx. 1 mm between the
puller roller and the presser foot.
● Tighten screw 2.
When using the adapter, the
height of the puller roller must
be adjusted as described in
Chapter 2.02.
Fig. 1 - 01
1
2
1 mm
3
