Parameter Settings
20
9 985 Switch on angle for thread trapper B, C 0 -255 67
986 Switch off angle for thread trapper B, C 0 -255 206
989 Thread trapper at beginning of seam B, C 0 - 2 0
1 = yes, 0 = no
10 1001 Stepping motor starting angle B, C 0 - 255
1181, 3701 25
1183 170
5483 144
1003 Feed roller radius C 5 - 50 15
11 1100 Operating mode stepping motor 1 C 0 - 2 1
1101 Rotation direction stepping motor 1 C 0 - 1 0
1 = anti-clockwise, 0 = clockwise
1102 Stepping mode stepping motor 1 C 0 - 4 3
1 = full-step, 2 = half-step,
3 = quarter step, 4 = eighth step
1103 Maximum current stepping motor in % C 0 - 100 50
1104 Reducing current stepping motor in % C 0 - 50 30
1105 Stepping motor 1, start-stop-time C 10 - 4000 180
(time for 1
st
step at start-stop-speed)
1106 Maximum speed stepping motor 1 C 10 - 4000 843
1107 Acceleration in % of max. speed on C 1 - 50 28
stepping motor 1
1108 Number of brake steps of stepping motor 1 C 1 - 50 5
1160 Feed motion compensation at beginning of seam A, B, C 0 - 99 20
The standard values listed in the table are basic settings, which can be
altered if necessary.
Further parameters are contained in the Motor Instruction Manual
V
See Chapter 3 Specifications in the machine Instruction Manual.
* Adjustment see Chapter 3.01 Basic position of the machine drive unit.
Group
Parameter
Description
Standard value
Adjustment
range
Access level
