Needle position crosswise to sewing direction
(on the PF
AFF 571)
Requirement
When the stitc
h length is set at its maximum, the needle must be positioned in the cen-
tre of the needle hole when entering and coming out of the needle plate.
T
urn screws
1
(scre
ws
2
, on both sides of the post) according to the
requirement
.
2
61-029
2
2
2
Fig. 1 - 07
Adjustment
15
17
