12 - 8
Adjustment
81-062
1
Fig. 12 - 07
2
12.05.06 Centering the needle in the needle hole (crosswise to sewing direction)
Requirement
With the zigzag stitch set at "0" and the needle position setting at "middle" the needle
must enter the center of the needle hole as seen across the direction of sewing.
Adjust the eccentric pin 1 (nut 2) in accordance with the requirement.
