65
● Fold the baseplate towards the machine.
● Attach the cable clip.
● Fasten the baseplate on the housing with the three fastening screws.
● Attach the face plate.
● Attach connection plug 2 onto the circuit board of the front housing shell.
● Install the sewing lamp cable.
● Mount the facing panel of the front housing panel.
● Insert the housing insert and fasten with the torx screws.
● Attach the top cover.
● The following points must be checked and adjusted:
● Section 17 "Adjustment of bobbin thread tension"
● Section 18 "Adjustment of needle thread tension"
● Section 20 "Adjustment of equal forward and reverse stitch length"
● An electrical safety test must be carried out in accordance with VDE 0701 using the testing appliance
Metrawatt 5013.
