Pfaff hobby 1122 User Manual

(B)
(B)
(C)
(A)
(D)
(E)
(1)
(2)
(3)
104 72 62-26 7
Remove the face plate, base cover and front cover.
Remove the set screws (A), (B), (C) and (D).
Lower the presser foot lifter (E) and pull away the rear cover from the machine, clearing
the parts (1), (2) and (3), in this order.
To attach
Follow the above procedure in reverse.
Rear cover

Pfaff hobby 1122 Specifications

General

Brand	Pfaff
Model	hobby 1122
Category	Sewing Machine
Language	English
