Threading the upper looper (red)
1. Pass the thread from back to front through the thread guides
on the thread stand (1).
2. Pull the thread from left to right under the thread guide at
the back on the top cover (2).
3. Lift up the handle and bring the thread under it. While
holding the thread with both hands, pass it between the
tension discs and pull it down to make certain it is properly
placed between the tension discs (3).
4. Thread the looper area of the machine following the red
color coded thread guides (4-7). Use the tweezers to make
the threading easier.
5. Use the tweezers to bring the thread behind the lower
looper and thread into the hole in the upper looper from
front to back (8).
6. Pull about 10 cm of thread through the looper and it place to
the back of the stitch plate.
