Pfaff powerquilter 16.0 - Front Side View; Components (Rear and Front Views)

Page 10
1. Thread Stand
2. Thread Guide A
3. Three-Hole Thread Guide B
4. Thread Guide C
5. Top Thread Tension Assembly
6. Stirrup Thread Guide E
7. Take-Up Lever
8. Thread Guide F
9. Front Casing/Frame
10. Hand Wheel
powerquilter
™
16.0 Quilting Machine Components
Front Side View
Figure 1
1.
10.
2.
3.
4.
5.
6.
7.
8. 9.
