Page 12
21. On/Off Switch
22. Power Cord Connector
23. Foot Pedal Connector
24. Spool Pins
25. Thread Stand
26. Bobbin Assembly
27. LED Light Ring
Rear and Front Views Included Accessories
Rear Front
Figure 3
H
DETAIL H
SCALE 1 : 2
4 M-Class Bobbins
INSPIRA® Needles Size 16
Bobbin Case Screwdriver
Lint Brush
Pen Oiler
Power Cord
H
DETAIL H
SCALE 1 : 2
21.
22.
23.
24.
25.
26.
27.
