Pfaff powerquilter 16.0 User Manual

Page 11
18. Back Casing/Frame
19. Color Touch-Screen Display Connector
20. Threaded Horizontal Spool Pin Mounting Hole
11. Needle Bar
12. Needle Bar Thread Guide
13. Needle
14. Hopping Foot
15. Needle Plate
16. Needle Clamp Screw
17. Front Display
Back Side View
Figure 2
H
DETAIL H
SCALE 1 : 2
H
DETAIL H
SCALE 1 : 2
11.
16.
13.
14.
15.
12.
17.
18.
19.
20.
Detail H

Pfaff powerquilter 16.0 Specifications

General

Brand	Pfaff
Model	powerquilter 16.0
Category	Sewing Machine
Language	English
