Pfeiffer Vacuum OKTA 500 User Manual

Type designation Okta 500 Okta 500 M
DN 2 DN 100 ISO-F DN 100 ISO-F
Ambient temperature 5 – 40 °C 5 – 40 °C
Shipping and storage temperature -10 – 40 °C -10 – 40 °C
Weight: with motor 140 kg 155 kg
Tbl. 12: Technical data Okta 500 Standard | M
14.3 Dimensions
96
200
222
170
B
A
Ø110
(4x M8-16/20)
15
140
Ø110
Ø134
Ø 70 H11 x 4,5
Ø 70 H11 x 4,5
220
260
150D
Ø12 (4x)
5
1
8
1
4
5
C
2
98
180
DN1
DN2
DN1
Fig. 14: Dimension diagram Okta 250 Standard | M
Dimensions in mm
Type designation Okta 250 Okta 250 M
A 769 mm 799 mm
B 297 mm 327 mm
C 337 mm 298 mm
D 183 mm 183 mm
Tbl. 13: Dimensions Okta 250 Standard | M
Technical data and dimensions
51/54
