Pfeiffer Vacuum TPG 300 User Manual

44 BG 805 970 BE (0306) TPG 300.oi
FI 3 Ö slow:
The TPG 300 does not
react on small
changes of measuring
value, has a slow
response time but
suppresses transients
effectively.
p
t
Data transfer rate of the RS232C Interface.
1234AB
mbar
Torr
Pa
A1
A2
B1
B2
PE
PE
010
Display Baud rate
bd 3
bd 1
bd 2
bd 4
bd 9
300
1200
2400
4800
9600
The Baud rates for the TPG 300 and any inter-
faced computer must be the same.
Using a Profibus-DP interface and relay board
IF 300P with the TPG 300, the Baud rate must
always be set to 9600 Baud (→  [8]).
5.7.6 »Interface« Group
»Baud Rate«
Function

Pfeiffer Vacuum TPG 300 Specifications

General

Display	LCD
Communication Interfaces	RS232, RS485, Ethernet
Temperature Range	0 to 50 °C
Accuracy	Dependent on connected gauges
Outputs	Analog, Relay
Operating Temperature	0°C to +50°C
Dimensions	96 mm x 96 mm
Type	Pirani Gauge Controller
