10. Technical data WK60 series
Supply voltage: 9 V to 36 V
Printers need 24 V, use a transformer if necessary.
Rated voltage: 24 V
Power consumpon including printer: max. 6 A
Protecon class per ISO 20653:2013-02: IP42 / IP5K2
Interfaces: Plugs:
1 x RS 232 D-Sub 9-pin (m)
2 x CAN (in acc. with ISO11898-2) 8 mm snap
1 x USB 3.0 USB A female
1 x USB 2.0 USB A female
1 x Ethernet (LAN) RJ 45
3 x Proximity switches (N1 to N3) 8 mm snap
2 x MIO 1/2 mulfunconal
input (10 kHz) /output (1 kHz) per 8 mm snap
1 x Analog-to-digital converter (ADC)/(12 bit) 8 mm snap
1 x Supply voltage (UBin = voltage in) 8 mm snap
1 x voltage protecve circuit
(UBout = voltage out), switchable 8 mm snap
Posion determinaon: GPS
WK60 unlocked
WK60-S optional
Data memory:
All data inclusive adjustment parameters and Alibi memory in the mounng pan.
Weight incl. aachment: roughly 1.8 kg
Environmental condions:
Operang temperature: -10 to +40 °C
Storage temperature: -20 to +70 °C
Maximum humidity: 95 % at +55 °C
Maximum altude: up to 2000 m (typical)
