PG Drives Technology S120A User Manual

S-DRIVE - INSTALLATION PG DRIVES TECHNOLOGY
SK76745/10
22
1 Documentation
1.1 S-Drive Operation
Study Chapter 1: Operation. It is important that the operation information in chapter 1 is supplied with the scooter, either as part
of the scooter user handbook or as a separate document.
This chapter sets out the installation conditions that must be complied with in order to meet the safety requirements of TÜV
(Germany), ISO7176-14 and EN12184.
1.2 Dimensions
1.2.1 S45A, S70A and S90A Controllers

PG Drives Technology S120A Specifications

General

Model	S120A
Category	Controller
Input Voltage	24VDC
Output Current	120A
Control Method	PWM (Pulse Width Modulation)
Protection Features	Overcurrent, Overvoltage, Overtemperature
