(D)Steering handlebar
1.Remove the LH/RH back mirrors.
2.Remove the upper handle cover.
3.Remove the nuts on front fork and handlebar.
4.Take off the fixing bolt.
5.Remove the nut and bolt of the front fork fixed on
The handlebar.
6.Take off the handle bar.
7.When assembling, please follow the opposite procedures.
8.Before assembling, please add grease on each cable.
Locking Torque:
M6 : 1.0-1.2kg-m
M10 : 3.0-4.0kg-m
