 Crankshaft

Item Standard value(mm) Limit of use.(mm)

Clearance of connecting rod big end

axle direction

0.005~0.013 0.05

Clearance of connecting rod big end

vertical direction.

0.10~0.40 0.8

Swingness of the crank shaft journal. 0.03 0.10
