3.4.Event ID Descriptions
Event ID
Description of Cause
E01
Bus Start Fail: DC-DC converter or bus sensing circuit
failed.
E02
Bus Volt High: DC-DC converter failed.
E03
Bus Volt Low: DC-DC converter failed.
E04
Bus Unbalanced: DC-DC converter failed.
E06
INV Start Fail: Inverter circuit failed.
E07
INV Volt High: Inverter circuit or output voltage
sensing circuit failed.
E08
INV Volt Low: The load may be too heavy or inverter
circuit failed.
E09
INV Short: The inverter circuit failed.
E11
Bat Volt High: The external battery module connection
is wrong, or the charger failed.
E12
Bat Volt Low: Batteries failed.
E14
Over Load: UPS is overloaded.
E18
Fan Fail: The ventilation hole has been covered, or the
fans can’t work.
E19
Over Temperature: High ambient temperature, or the
ventilation hole has been covered.
A56
Bat Volt Low: Battery voltage is low.
A57
Bat Cap Low: Battery capacity is low.
A59
Bat disconnect: Battery is disconnect.
A60
Overcharge: Charger voltage is high.
A61
Charger fail: Charger is failed.
A62
Bat Bad: Battery failed.
A64
Over Load warning: UPS is overload.
A66
EPO Off: Missing the EPO connection
A68
High Temperature: High ambient temperature, or the
ventilation hole has been covered. This is shown only
when start up UPS.
A69
Fan Lock: fans can’t work because of lock.
