phase II+ 220-006 - Replacement Parts List for Dividing Attachment

OperatingInstructions&PartsManual
 HorizontalRotaryTables
 DividingPlates
Pg. 6

Figure3‐ReplacementPartsIllustrationforModel241‐101
ReplacementPartsListforDividingAttachment
ReferenceNo.
Description
PartNo. Qt
y
1 Dividingplatewith34‐41and43‐61holes 9283 1
2 Dividingplatewith46‐53and54‐66holes 9284 1
3 4‐0.7x16mmFillisterheadscrew 9285 4
4 Sector 9286 1
5 Springwasher 9287 1
6 Spacer 9288 1
7 Crankarm 9289 1
8 PlungerAssembl
y
 9290 1
9 Handle 9291 1
10 HandleScrew 9292 1
Figure3–ReplacementPartsIllustrationfor
 241‐101DividingAttachment
