4.8.3 Viewing/deleting stored record
This function provides the user with the ability to view/delete a record in a desired file previously saved in
memory. Following is the steps:
1. Press the
key to activate the data logging functions. It will display the current file name and the total
record count of the file.
2. Use the
key and the key to select the desired file.
3. Press the
key to enter the selected file. It will display the current record number (for example, L012) and
the record content.
4. Use the key and the key to select the desired record.
5. Press the
key on the desired record. It will automatically delete this record, and display “-DEL”.
6. Press the
key to exit the data logging functions and return to measurement mode.
4.9 Data Printing
At the end of the inspection process, or end of the day, the user may require the readings be transferred to a
computer. The following steps outline this procedure.
Before printing, please insert one connection plug of the print cable (Optional parts) into the socket on the
upper-left of the main body, and insert the other plug into the communication socket of the mini-printer.
1. Press the
key to activate the data logging functions.
2. Use the
key and the key to select the desired file.
3. Press the
key to print the selected file. This operation will send all the data in current file to the mini
printer via RS232 port and print them out.
4. Press the
key to exit the data logging functions and return to measurement mode.
4.10 Sound Mode
When the sound is set to 【On】，it would make a short beep any time you press a key, take a measurement,
or the measured value exceeds the tolerance limit.
Press the
key to switch the beep mode on and off. It will display the current sound mode on the main
screen.
4.11 EL Backlight
The background light makes it easy to use in darker conditions indoors or out. Press key
to switch on or
switch off the background light at any moment as you need after power on. Since the EL light will consume more
power, turn on it only when necessary.
4.12 Battery Icon
Two AA size alkaline batteries are used as the power source. As the battery begins to drain the display will
be shown as
. When the battery capacity runs out, the battery symbol will be shown as and will
begin to flash. When this occurs, the batteries should be replaced. Pay close attention to polarity.
Please remove batteries if the UTG-2800 will not be used for an extended period of time.
