Phase LHX Series - Page 46

39 | P a g e
DISPLAY
MESSAGE
DESCRIPTION
DEFAULT [UNITS]
(MIN - MAX)
1.1.27 Skip
Frequencies
@
Press ENTER to see the following parameters related to Skip Frequencies.
1.1.27.1 Skip
Frequency 1
Setpoint
Sets the first frequency to skip during acceleration and deceleration
ramps.
Disabled (0 - 1.1.2
MAX FREQUENCY)
1.1.27.2 Skip
Frequency 1
Bandwidth
Sets the width of the frequency band to be skipped. Skipped frequencies
will center around 1.1.27.1 SKIP FREQUENCY SETPOINT 1.
0 Hz (0-300)
1.1.27.3 Skip
Frequency 2
Setpoint
Sets the second frequency to skip during acceleration and deceleration
ramps.
Disabled (0 - 1.1.2
MAX FREQUENCY)
1.1.27.4 Skip
Frequency 2
Bandwidth
Sets the width of the frequency band to be skipped. Skipped frequencies
will center around 1.1.27.3 SKIP FREQUENCY SETPOINT 2.
0 Hz (0-300)
1.1.27.5 Skip
Frequency 3
Setpoint
Sets the third frequency to skip during acceleration and deceleration
ramps.
Disabled (0 - 1.1.2
MAX FREQUENCY)
1.1.27.6 Skip
Frequency 3
Bandwidth
Sets the width of the frequency band to be skipped. Skipped frequencies
will center around 1.1.27.5 SKIP FREQUENCY SETPOINT 3.
0 Hz (0-300)
1.1.29 Current
Unbalance
@
Percent current unbalance allowed on output phases.
80 % (1 – 100)
1.1.30 DC Bus
Ripple
Compensation
@
When enabled, this allows output voltage to vary to keep current stable.
Disabling this feature will result in stable output voltage but current may
oscillate.
Enable
$ - Parameters are only visible when 1.3.2 MENU COMPLEXITY is set to STANDARD.
@ - Parameters are only visible when 1.3.2 MENU COMPLEXITY is set to ADVANCED.
