Notice
Please add the following NOTICE to the Manuals listed below.
1. Effective Models and Production
MDF-C8V1-PK, PR S/N: 15100227~
2.
Change Description
Panasonic Healthcare Co., Ltd.
CORRECTION
SERVICE
PRODUCT IMPROVEMET
PRODUCTION CHANGE
ADD INFORMATION
FOR RoHS
FILE NO.
Category: Ultra Low Temperature Freezer Date: Jan. 7, 2016
Model: MDF-C8V1
Ref No: SM9910171 Issued No. E301
REFERENCE NO. SM9910171
SM9910171SM9910171
SM9910171-
--
-07
0707
07
NOTICE
Because of parts discontinuance, below parts have been changed of Service Manual
Contents
OLD NEW
P.1 The descriptions about "Structural specifications" is changed as follow;
P.72 The descriptions about "SPECIFICATIONS" is changed as follow;
Item
Specifications OLD NEW
P.3 The descriptions about "Performance specifications" is changed as follow;
P.73 The descriptions about "PERFORMANCE" is changed as follow;
Item
Specifications OLD NEW
P.5 The descriptions about "Cooling unit parts" is changed as follow;
Item
Specifications OLD NEW
Compressor
Type C-1RN40L6A C-1RN45L6A
Compressor cord 802 012 16 802 021 162
MU-N49
MU-N48 (only for 220V, 60Hz)
390g
375g (only for 220V, 60Hz)
P.8 The descriptions about "Electric Parts" is changed as follow;
MDF-C8V1
AC 220V, 60Hz OLD NEW
Compressor Type C-1RN40L6A C-1RN45L6A
Compressor code 802 012 16 802 021 162
Winding resistance
C-R(Main)
5.34
Ω
(25
℃
) 4.77
Ω
(25
℃
)
C-S(Aux) 8.88
Ω
(25
℃
) 8.36
Ω
(25
℃
)
Running
capacitor
Rating 10 µF 400VAC 12 µF 370VAC
- You should use 'MU-N49'
for servicing.
Upon unit repair:
<For 220V, 60Hz>
Rated Power
consumption
350W
Compressor Hermetic rotary type, 400W
Hermetic rotary type,
400W / 450W (220V, 60Hz)
220V, 60Hz 360W
- You shoud use 'MU-N49 or MU-N48'
for servicing.
Refrigerant
Type
Charged q'ty
MU-N49
390g
