＜Distribution data＞
Temperature of the cycle in each area (SV=-70℃、air temperature)
Unit:℃
Maximum Minimum
Middle of
cycle
Differential
①
Left back
-67.5 -71.6 -69.6 ±2.1
②
Right back
-68.0 -71.5 -69.8 ±1.8
③
Right front
-68.1 -71.8 -70.0 ±1.8
④
Left front
-68.3 -72.1 -70.2 ±1.9
⑤
Center
-68.4 -70.8 -69.6 ±1.2
⑥
Left back
-68.8 -71.9 -70.4 ±1.6
⑦
Right back
-68.7 -71.7 -70.2 ±1.5
⑧
Right front
-68.6 -71.8 -70.2 ±1.6
⑨
Left front
-68.9 -71.8 -70.4 ±1.5
⑩
Center
-69.1 -71.2 -70.2 ±1.1
⑪
Left back
-68.3 -71.1 -69.7 ±1.4
⑫
Right back
-68.1 -71.2 -69.7 ±1.6
⑬
Right front
-68.1 -71.3 -69.7 ±1.6
⑭
Left front
-68.4 -71.4 -69.9 ±1.5
⑮
Center
-68.6 -71.0 -69.8 ±1.2
- - -69.9 -
Unit:℃
Maximum Minimum
Middle of
cycle
Differential
①
Left back
-67.5 -71.5 -69.5 ±2.0
②
Right back
-68.0 -71.5 -69.8 ±1.8
③
Right front
-68.2 -71.8 -70.0 ±1.8
④
Left front
-68.2 -72.0 -70.1 ±1.9
⑤
Center
-68.4 -70.8 -69.6 ±1.2
⑥
Left back
-68.8 -72.0 -70.4 ±1.6
⑦
Right back
-68.6 -71.7 -70.2 ±1.6
⑧
Right front
-68.5 -71.6 -70.1 ±1.6
⑨
Left front
-68.7 -71.7 -70.2 ±1.5
⑩
Center
-69.0 -71.0 -70.0 ±1.0
⑪
Left back
-68.4 -71.2 -69.8 ±1.4
⑫
Right back
-68.1 -71.3 -69.7 ±1.6
⑬
Right front
-68.1 -71.3 -69.7 ±1.6
⑭
Left front
-68.4 -71.4 -69.9 ±1.5
⑮
Center
-68.6 -70.9 -69.8 ±1.2
- - -69.9 -
＜Amount of power consumption＞
Amount of power consumption when driving at cycle
(SV=-70℃）
1φ115V
Unit：kWh/day
50Hz 60Hz
AT23℃
3.81
ＡＴ30℃ 4.24
Ambient temperature 23℃
115V 60Hz
Upper area
Middle area
Bottom area
Average
Ambient temperature 30℃
115V 60Hz
Upper area
Middle area
Bottom area
Note:This data does not represent a guarantee of product performance.
Note:This data does not represent a guarantee
of product performance.
Average
