For HITACHI compressor
Compressor
Type RL4588-P1 RL4588-R1 RL4588-S1
Compressor code 7FB-0-M101-020-02 7FB-0-M101-020-04 7FB-0-M101-020-03
Rated voltage (50/60Hz) φ1, 110~115V, 60Hz φ1, 220V, 60Hz φ1, 220~240V, 50Hz
Winding resistance C-R(Main) 0.89Ω(25℃) 3.52Ω(25℃) 5.23Ω(25℃)
C-S(Aux) 4.19Ω(25℃) 10.90Ω(25℃) 9.56Ω(25℃)
Starting relay
Type P6R0SAT PGR0SAT PGR0SAT
Starting capacitor Rating 100μF, 160VAC 60μF, 300VAC 60μF, 300VAC
Running capacitor Rating 35μF, 260VAC 6μF, 400VAC 6μF, 400VAC
Condensing fan motor
Type SE4-D041N1P SE4-D041N5P SE4-D041N5P
Rating 110~115V, 4W 220~240V, 4W 220~240V, 4W
AC110/115V, 60Hz
AC220V, 60Hz
AC220/230/240V, 50Hz
Electrical Parts
