MDF-C8V1(-PT) Internal Temperature Uniformity (Reference Data)
＜Conditions＞
Ambient temperature: 23/30℃
Load: Unloaded
＜Distribution data＞
Temperature of the cycle in each area (SV=-80℃、air temperature)
Unit:℃
Maximum Minimum
Middle of
cycle
Differential
①
Left back
-77.6 -81.2 -79.4 ±1.8
②
Right back
-78.0 -81.1 -79.6 ±1.6
③
Right front
-78.1 -81.4 -79.8 ±1.7
④
Left front
-78.3 -81.6 -80.0 ±1.7
⑤
Center
-78.3 -80.5 -79.4 ±1.1
⑥
Left back
-78.8 -81.6 -80.2 ±1.4
⑦
Right back
-78.7 -81.4 -80.1 ±1.4
⑧
Right front
-78.5 -81.4 -80.0 ±1.5
⑨
Left front
-78.8 -81.4 -80.1 ±1.3
⑩
Center
-78.9 -80.9 -79.9 ±1.0
⑪
Left back
-78.3 -80.7 -79.5 ±1.2
⑫
Right back
-78.0 -80.9 -79.5 ±1.5
⑬
Right front
-78.1 -81.0 -79.6 ±1.5
⑭
Left front
-78.3 -81.0 -79.7 ±1.3
⑮
Center
-78.5 -80.7 -79.6 ±1.1
- - -79.7 -
Unit:℃
Maximum Minimum
Middle of
cycle
Differential
①
Left back
-77.5 -81.0 -79.3 ±1.8
②
Right back
-77.9 -81.0 -79.5 ±1.6
③
Right front
-78.2 -81.2 -79.7 ±1.5
④
Left front
-78.2 -81.4 -79.8 ±1.6
⑤
Center
-78.3 -80.4 -79.4 ±1.1
⑥
Left back
-78.8 -81.5 -80.2 ±1.3
⑦
Right back
-78.6 -81.4 -80.0 ±1.4
⑧
Right front
-78.6 -81.3 -80.0 ±1.4
⑨
Left front
-78.8 -81.3 -80.1 ±1.3
⑩
Center
-79.0 -80.9 -80.0 ±1.0
⑪
Left back
-78.2 -80.7 -79.5 ±1.3
⑫
Right back
-78.0 -80.8 -79.4 ±1.4
⑬
Right front
-78.0 -80.9 -79.5 ±1.5
⑭
Left front
-78.3 -80.9 -79.6 ±1.3
⑮
Center
-78.5 -80.6 -79.6 ±1.1
- - -79.7 -
Note:This data does not represent a guarantee of product performance.
＜Amount of power consumption＞
Amount of power consumption when driving at cycle
(SV=-80℃）
1φ110V
Unit：kWh/day
50Hz 60Hz
AT23℃
4.50
ＡＴ30℃ 5.08
Average
Note:This data does not represent a guarantee
of product performance.
Upper area
Middle area
Bottom area
110V 60Hz
Upper area
Middle area
Bottom area
Average
Ambient temperature 30℃
Ambient temperature 23℃
110V 60Hz
