34
SPECIFICATIONS
Product name
Biomedical Freezer
MDF-MU339
Biomedical Freezer
MDF-MU539
External dimensions W616 mm x D770 mm x H1802 mm W793 mm x D770 mm x H1802 mm
Internal dimensions W472 mm x D614 mm x H1262 mm W649 mm x D614 mm x H1262 mm
Effective capacity 369 L 504 L
Exterior Painted steel
Interior Painted steel
Insulation Rigid polyurethane foamed-in place
Outer door Painted steel
Shelf
Made of hard steel wire + PE coating : 6 pcs
Load; 30 kg/shelf
Evaporator Tube on sheet type (Liner combined use)
Access port Diameter 30 mm, 1 on back side
Condenser Wire and tube type
Compressor Hermetic type, 250 W
Refrigerant R-404A
Temperature controller Microcomputer control system
Temperature display Digital display (between -50
o
C and +50
o
C)
Temperature sensor Thermistor sensor
Temperature alarm Flash of digital temperature indicator and alarm lamp, Buzzer, (Remote alarm)
Remote alarm contact
Allowable contact capacity: DC 30 V, 2 A *1
Accessories
Key 1 set, Defrost spatula 1 pc
Storage container : 6 pcs Storage container : 12 pcs
Weight 135 kg 163 kg
Battery
For power failure alarm, Nickel-metal-hydride battery,
DC 6 V, 1100 mAh, Automatic charge
Optional component
Temperature recorder (MTR-G85C)+Recorder fixing (MPR-S7),
Temperature recorder (MTR-4015LH)+ Recorder fixing (MPR-S30)
Interface board (MTR-480, MTR-L03) *1, *2
*1: It is recommended to use standard signal and interface cables with a maximum length of 30 meters.
*2: For the data acquisition system MTR-5000 user only. Contact our sales representative or agent for purchase.
Note:
• Design or specifications are subject to change without notice.
• Refer to the updated catalogue when ordering an optional component.
