Phcbi MDF-U443 - Temperature Recorder (Option)

33
TEMPERATURE RECORDER (OPTION)
The chamber temperature can be monitored and recorded by installing an optional temperature recorder.
For the installation of a temperature recorder, an optional recorder fixing is necessary.
 For the attachment of a temperature recorder, contact our sales representative or agent.
 For the usage of the temperature recorder, also refer to an installation sheet enclosed with the
temperature recorder.
Main specifications of temperature recorder
MTR-85H MTR-4015LH
Recording range Between -100
o
C and +50
o
C Between -40
o
C and +14
o
C
Feed speed of
recording paper
62-day/batch 31-day/batch
Recording paper Strip type Strip type
Power source Dry cell Dry cell
MTR-4015LH
MTR-85H
-
15
0
-
1
0
0
-
5
0
0
0
3
0
C
