Phenix Technologies 600P Series User Manual

6CP30/15-3
10-1
SECTION 10: 6CP30/15-3 PARTS LIST
ITEM
DESCRIPTION
QTY
PART NO.
CONTROLS
A1
PCB1257 METER/OVERLOAD BD (6CP30/15-3)
1
31125721
CB1 (220V)
CIRCUIT BREAKER, 10 AMP, 2-POLE
1
1601312
CB1 (120V)
CIRCUIT BREAKER, 20 AMP, 1-POLE
1
1601320
CORD
INPUT POWER CORD
1
1077140
F1
FUSE, 1 AMP
1
1603601
F1, F2
FUSE HOLDER
1
1603920
F2 (220V)
FUSE, 10 AMP
1
1603625
F2 (120V)
FUSE, 20 AMP
1
1603629
K3 (220V)
CONTACTOR 30A, 3 POLE
1
1705462
K3 (120V)
CONTACTOR 30A, 1 POLE
1
1705463
LP1, SW7, 8 LENS
CLEAR LENS EAO
3
1422153
LP1 SOCKET
LAMP SOCKET EAO
1
1423300
LMP1, SW1, 2, 4, 7
LAMP 60V EAO
5
1420150
M1, M2
METER, DIGITAL, 3 ½ DIGIT
2
1506400
M1, M2
CONNECTOR, 10 CKT, 0.1
2
1152210
M1
METER PROTECTION BOARD (ZENERS ONLY)–
PCB1265
1
31126500
M2
METER PROTECTION BOARD – PCB1265
1
31126501
MOV1 (220V)
MOVISTOR, V275LA40A
1
1606110
MOV1 (120V)
MOVISTOR, V130LA10A
1
1606100
P1
POWER INPUT RECEPTACLE
1
1153328
R1
POTENTIOMETER, LINEAR, 10K, 2W
1
1761098
R1 DIAL
BLACK STATOR
1
1355905
R1 DIAL
0-11 NUMBERED DIAL
1
1355910
R1 KNOB
BLACK KNOB
1
1355101
R1 KNOB
KNOB CAP
1
1355102
R2
RESISTOR, 30k, .25W
1
1722570
R3
RESISTOR, 3.0k, .25W
1
1722087
R4
RESISTOR, 300 OHMS, .5W
1
1720600
R5
RESISTOR, 30 OHMS, 3W
1
1740184
R6
RESISTOR, 30 OHMS, 3W
2
1740184
SW2 LENS
LENS, RED EAO
1
1422150
SW1 LENS
LENS, GREEN EAO
1
1422151
SW1,2,4
SWITCH, PUSHBUTTON, MOMENTARY, 1-POLE
3
1860120
SW3
SWITCH, ROLLER, CAM, ZERO START
1
1866005
SW4 LENS
LENS, BLUE EAO
1
1422148
SW5
SWITCH, ROTARY, 4-POSITION
1
1863042
SW5,6 KNOB
KNOB, ¼”
2
1355310
SW6
SWITCH, ROTARY, 2-POSITION
1
1863048
SW7
SWITCH, PUSHBUTTON, MAINTAINED, 2-POLE
1
1860265
SW8
SWITCH, PUSHBUTTON, MAINTAINED, 1-POLE
1
1860260
SX1
RECEPTACLE, 4F PINS, SIZE 11
1
1151152
SX1
CONTACT PINS, 24-20AWG, FEMALE
1
1151174
SX1 PLUG
SX1 AMP PLUG
1
50100001
