Phenix Technologies 6CP200/100-10 User Manual

6CP200/100-10
15-1
SECTION 15: 6CP200/100-10 PARTS LIST
Item
Part Number
Description
Quantity
CONTROL/REGULATOR
CB1,CB2
1601332
2P CIRCUIT BREAKER
1
CON1
1151178
RECEPTACLE
1
CON1
1151183
HIGH CURRENT PINS, MALE
3
CON2
1151179
RECEPTACLE
1
CON2
1151185
HIGH CURRENT PINS, FEMALE
2
D1-D5
1780028
DIODE
5
DX1
1151152
RECEPTACLE,
1
DX1
1151174
CONTACT PINS, FEMALE
2
F1, F2 (220 V)
1603601
FUSE
2
F1,F2
1603920
FUSEHOLDER
2
HANDLES
2101710
HANDLE
2
K3 (220 V)
1705465
CONTACTOR
1
LP1
1423300
SOCKET
1
LP1, LP4,SW10
1420163
WHITE LED LAMP
3
LP1,SW10,SW11
1422153
LENS CLEAR
1
LP2
1422150
RED LED LAMP
1
LP3
1420161
GREEN LED LAMP
1
M1,M2
1506400
3 ½ DIGIT LCD
2
M1,M2
31138800
METER INTERFACE BD
1
M1,M2
1152152
CONNECTOR
4
M1,M2
1079909
RIBBON CABLE
N/A
MOV1 (220 V)
1606110
MOVISTOR
1
PCB1387
31138715
6CP200/100-10 CONTROL/METERING BD
1
R15
1761098
POTENTIOMETER
1
R15 -CAP
1355102
PEAKED CAP
1
R15 KNOB
1355101
KNOB
1
R15-DIAL
1355910
DIAL
1
R15-KNOB
1355905
KNOB
1
R16A-B
1710400
RESISTOR
2
SPACER
1350110
PCB SPACER
6
SW10
1860265
SWITCH 2POLE
1
SW11
1860260
SWITCH 1POLE
1
SW2,3,4
1860120
SWITCH, 1 POLE
3
SW2/ LP2
1422150
LENS, RED
1
SW3/ LP3
1422151
LENS, GREEN
1
SW4/ LP4
1422148
LENS, BLUE
1
SW5
1863042
SWITCH.
1
SW5, SW9
1355310
KNOB
2
SW7
1866005
ROLLER SWITCH
1
SW8
1860900
LATCHING MUSHROOM BUTTON
1
SW8
1862905
SWITCH
1
SW9
1863048
SWITCH
1
SX1
1151152
RECEPTACLE
1
SX1
1151174
PINS, FEMALE
2
SX1 CBL
1151162
CBL PLUG
1
SX1 CBL
1151176
PINS, MALE
2
SX1 CBL
1151186
CABLE CLAMP
1
T1
1890239
VARIABLE AUTO TRANSFORMER
1
T2
1896017
CONTROL POWER TRANSFORMER
1
TIMER
1480120
PANEL MOUNT DIFITAL TIMER
1
TX1
1151158
RECEPTACLE
1
