6CP200/100-10
15-2
Item
Part Number
Description
Quantity
CONTROL/REGULATOR CONTINUED
TX1
1151170
PINS, MALE
9
INPUT CBL
30110007
BK130 INPUT POWER CBL-30',10/3
1
GND CBL
30080008
GROUND CABLE, 10FT
1
GND CBL
30080019
GROUND CABLE, 30FT
2
RTN CBL
30080020
RTN CBL, 30FT, PLIER CLIP
1
DX1 CBL
30180006
DIVIDER INTERCONNECT CABLE
1
PWR CBL
30110008
BK130 PWR INTERC0NNECT-20',10/2
1
TX1 CBL
30160001
20' ST-ST 6PR SHL'D CABLE ASSY
1
HIGH VOLTAGE MODULES
|| CBL
30110042
PARALLELING CABLE
1
BP GND
1351103
BINDING POST (GREEN)
1
BP GRD
1351104
BINDING POST (WHITE)
1
BP RTN
1351102
BINDING POST (RED)
1
BP SHORT
1351110
BINDING POST SHORTING BAR
1
CAPS
1151196
SEALING CAP
3
CON3
1151178
RECEPTACLE
1
CON3
1151183
HIGH CURRENT PINS, MALE
2
CON4
1151179
RECEPTACLE
1
CON4
1151184
FEMALE CONTACT PIN
1
CON4
1151185
HIGH CURRENT PINS, FEMALE
3
D501-4
1780066
TRANZORB
4
H1-2
1356214
MULTILAM JACK
2
H1-2
1356212
MULTILAM PLUG
2
JUMPER
30180007
JUMPER SET
1
MOV301-10 (220 V)
1606110
MOVISTOR
10
PCB 1070
1110700
PCB 1070
1
PCB 1223
1112232
PCB 1223
1
R505A-B
1740395
RESISTOR
2
R507
1722570
RESISTOR
1
R508
1722087
RESISTOR
1
R509
1720600
RESISTOR
1
R510
1740185
RESISTOR
1
SPG501-502
1605110
SPARK GAP
2
T301-302
3834-2690
PHENIX TRANSFORMER GO1-2690
2
TX1
1151158
RECEPTACLE
1
TX1
1151170
PINS, MALE
8
X1-3, T1-2
1356312
MULTILAMM PLUG
4
X1-3, T1-2
1356310
MULTILAMM SOCKET
8
HIGH VOLTAGE DIVIDER
C601-602
1090304
CAPACITOR
2
DX1
1151152
RECEPTACLE
1
DX1
1151175
CONTACT PINS, FEMALE
3
GROUND
1351103
BINDING POST GREEN
1
NE2
1609990
NEON LAMP
1
PCB 1282
31128204
PCB 1282
1
TB601
1156050
TERMINAL STRIP
1
