Phenix Technologies 6CP50/10-3 User Manual

6CP50/10-3
15-2
PARTS LIST
ITEM
DESCRIPTION
QTY
PART NO.
CONTROLS (continued)
T1 (220V)
STACO 1220 VARIABLE TRANSFORMER
1
1890215
T1 (120V)
STACO 1210 VARIABLE TRANSFORMER
1
1890209
T2 (220V)
50VA CNTRL TRANSFORMER 240/480 : 120/240
1
1896017
TMR1
TIMER, OMEGA #PTC-13
1
1480120
TX1
RECEPTACLE, HIGH CURRENT, 3F PINS, SIZE 17
1
1151179
TX1
FEMALE CONTACT PINS, 16-12AWG
2
1151184
TX2
RECEPTACLE, 9M PINS, SIZE 13
1
1151154
TX2
MALE CONTACT PINS, 24-20AWG
7
1151170
HV TRANSFORMER
BP-GROUND
BINDING POST, GREEN
1
1351103
BP-GUARD
BINDING POST, WHITE
1
1351104
BP-RETURN
BINDING POST, RED
1
1351102
SHORTING BAR
BINDING POST SHORTING BAR
1
1351110
D3001-D3002
TRANSORB, 5KP13A
2
1780066
D3003-D3004
TRANSORB, 1.5KE18A
2
1780065
D3005-D3006
TRANSORB, 1.5KE18C
2
1780069
MOV3001 (220V)
MOVISTOR, V275LA40A
1
1606110
MOV3001 (120V)
MOVISTOR, V130LA10A
1
1606100
R3001
RESISTOR, 50 MEG, 10 W, 1%
1
1747100
R3002
RESISTOR, 200 MEG, 10 W, 1%
1
1748415
R3003, R3004
RESISTOR, 200K, 1/2W, 1%
2
1722640
R3005
RESISTOR, 100 OHM, 5W
1
1740295
SPG3001-3002
SPARK GAP, CG90L, 90V
2
1605110
T3001
HIGH VOLTAGE TRANSFORMER, GO1-3037
1
38343037
TX1
RECEPTACLE, HIGH CURRENT, 3M PINS, SIZE 17
1
1151178
TX1
MALE CONTACT PINS, 16-12AWG
2
1151182
TX1
SIZE 17 CAP
1
1151196
TX2
RECEPTACLE, 16M PINS, SIZE 17
1
1151158
TX2
MALE CONTACT PINS, 24-20AWG
7
1151170
TX2
SIZE 17 CAP
1
1151196
INTERCONNECT CABLES
TX1 CABLE
POWER INTERCONNECT CABLE – 6 FT 7 IN.
1
1077140
TX2 CABLE
SIGNAL INTERCONNECT CABLE- 10 FT
1
30060008
GND CABLE
10 FT. GROUND CABLE ASSY.
1
30080008
RTN CABLE
10 FT. SPECIMEN RETURN CABLE ASSY.
1
30080009
