HC-2
6-1
SECTION 6: HC-2 PARTS LIST
ITEM PART NO. DESCRIPTION QTY
CB1 1601395 CKT BRKR HOLE COVER (120V) 1
CB1,CB2 1601330 30A 1P CKT BRKR 250V (CE) (120V) 2
CB1 1601317 15A 2P CKT BRKR 250V (CE) (220V) 1
CB2 1601315 15A 1P CKT BRKR 250V (CE) (220V) 1
CT1 1892206 CURRENT TRANS. 1000/1 1
F1 1603603 AGC-3 (120V) 1
F1 1603602 AGC-1.5 (220V) 1
F1 1603920 1P PNL MNT FUSEHLDER (3 AG) 1
J1,J2 1151955 JUMPER-JAX ROHS 2
LP1,3 1422150 LENS, EAO RED 2
LP1-4 1420143 EAO LAMP 6.3V 4
LP2 1422151 LENS, GREEN 1
LP4 1422152 LENS YELLOW 1
M1 1506400 KNS DMO-66PHX 3 1/2 DIG LCD 1
MOV1,2 1606100 MOVISTOR V130LA10A (120V) 2
MOV1,2 1606110 MOVISTOR V275LA40A (220V) 2
PCB1361 31136100 PCB1361: HC CNTRLS AND PWR ASSY 1
PS1 1590110 PS 5VDC,5A, SW-OPEN FRAME 1
R200,201 1741990 10W, 1K, 1% WIREWOUND 2
PCB1223 31122305 PCB1223 ASSY FOR HC 0.3,1,2,3 1
SSR1 1700345 SOLID STATE RELAY 40A (120V) 1
SSR1 1700335 CRYDOM RELAY 25A (220V) 1
SW1,3,4,5 1860120 EAO, MOM. 1POLE 4
SW2,8,9 1865010 MPC223 PCB TOGGLE 3
SW6 1355310 KNOB 1
SW6 1863047 ROTARY SW 2P 2-6 POS-S 1
T1 1890231 STACO 1510 VARIAC 1
TIMER 1505421 BEZEL KIT 1
TIMER 1505420 MDMU0000 RED LION COUNTER/TIMER 1
T2 38321185 GA1-1185 1
