PHI VILLA E02GF143 - User Manual

Questions and Answers

X
xlynchAug 5, 2025
What to do if PHI VILLA E02GF143 Indoor Furnishing has low heat output on high setting?
- S
  shannon83Aug 5, 2025
  If the valve is set to high on your PHI VILLA Indoor Furnishing but there is low heat output, accompanied by a rumbling noise and a fluttering blue flame at the burner surface, it may be due to several reasons. First, check the gas level in the propane cylinder. Next, make sure the supply hose is not pinched. Also, the burner orifice may be dirty or clogged, or there could be spider webs or other matter in the venturi tube. Finally, the propane regulator might be in a “low flow” state. Clean the burner orifice and the venturi tube. Ensure the lighting procedure is followed carefully: all valves must be in the off position when the tank valve is turned on, and turn the tank on slowly to allow pressure to equalize.
V
Vincent JohnsonAug 15, 2025
How to fix PHI VILLA Indoor Furnishing burner that won't light with igniter?
- A
  Andrea BarnesAug 15, 2025
  If the burner of your PHI VILLA Indoor Furnishing will not light with the igniter but will light with a match, the battery may be dead or installed incorrectly. Additionally, there may be a loose electrode wire or switch terminal wires. Check the installation or replace with a new battery. Check that the electrode wire is firmly pushed onto the terminal on the back of the igniter. Check that the lead wires from the module to the ignition switch (if equipped) are firmly pushed onto their respective terminals.
K
Kimberly AdamsAug 20, 2025
Why is PHI VILLA E02GF143 Indoor Furnishing flame low?
- R
  Ryan MontgomeryAug 20, 2025
  If your PHI VILLA Indoor Furnishing flame and heat are low when the valve is turned to high, it is possible that the propane lighting procedure was not followed correctly. Ensure the lighting procedure is followed carefully. The valve must be in the off position when the tank valve is turned on. Turn the tank on slowly to allow pressure to equalize. See Lighting Instructions in the Operating section.
G
garcialoriAug 25, 2025
What to do if PHI VILLA E02GF143 burners have yellow flame?
- T
  Tiffany HaleAug 26, 2025
  If the burners of your PHI VILLA Indoor Furnishing burn with a yellow flame and there is a smell of gas, there is possibly a spider web or other debris. Thoroughly clean the burner venturi. See the Maintenance section.
T
Tammy WilsonAug 30, 2025
Why is my PHI VILLA Indoor Furnishing regulator humming?
- T
  Tammy HopkinsAug 30, 2025
  The humming of the regulator in your PHI VILLA Indoor Furnishing is a normal occurrence on hot days. This is not a defect. It is caused by internal vibrations in the regulator and does not affect the performance or safety of the gas heater. A humming regulator will not be replaced.
I
ipalmerNov 9, 2025
Why does PHI VILLA Indoor Furnishing burner not stay lit?
- N
  Nicole VasquezNov 9, 2025
  If your PHI VILLA Indoor Furnishing burner will not stay lit when the control knob is released, there are several potential causes. The knob may not be held in long enough, or it could be too windy outside. Lava rock or debris in the ignition area of the burner may be preventing the thermocouple from being fully engulfed in flame. Also, the thermocouple or its connection might be dirty, or either the thermocouple or valve itself could be faulty. Hold the knob in for 30 seconds after the burner lights to allow the thermocouple to heat up. The unit will shut down if winds are greater than 10 mph (16 km/h), so relocate the fire pit or use it when it is less windy. Ensure there is no lava rock or other debris in the ignition area and that the small hole below the thermocouple is unobstructed. ...

Summary

Safety Information

General Safety Guidelines

Crucial safety guidelines for assembly and use of furniture.

Hazard Warnings

Highlights severe risks like choking hazards and incorrect assembly.

Warranty Information

Limited Warranty Terms

Details the one-year limited warranty for the furniture frame.

Warranty Coverage Details

Specifies what is covered and what is excluded by the warranty.

Pre-Assembly Preparation

Package Contents Identification

Lists all parts and hardware required for assembly.

Assembly Step 1 & 2

Frame and Panel Assembly

Connects legs to table top and attaches side panels.

Assembly Step 3 & 4

Window Panel and Tank Support

Attaches side panel with window and gas tank support.

Assembly Step 5 & 6

Door and Lid Installation

Attaches the door and places fire glass and lid.

Assembly Step 7

Securing Propane Cylinder

Places and secures the propane cylinder in the support.

Assembly Step 8

Installing Igniter Battery

Installs the AAA battery into the igniter.

Safety Information

Fire or Explosion Hazard

Instructions for handling gas leaks and potential fires.

Carbon Monoxide Hazard

Warns about CO production and enclosed spaces.

Outdoor Use and Installation Warning

Emphasizes outdoor use and qualified installation.

Safety Precautions

Covers general safety, property damage, and gas smell procedures.

Safety Information

Propane Cylinder Requirements

Details specifications for the propane cylinder and its use.

Cylinder Handling and Storage

Guidelines for handling, storing, and transporting propane cylinders.

Safety Information

Appliance Operation Safety

Covers safe operation, surface temperatures, and supervision.

Installation and Maintenance Safety

Stresses qualified installation, repair, and cleaning.

Pre-Assembly

Planning and Parts Check

Instructions for checking parts and storing the manual.

Tools and Hardware

Lists required tools and included hardware for assembly.

Package Contents

Fire Pit Component Identification

Visual identification of major parts A through K.

Package Contents

Detailed Parts List

Lists all components with descriptions and quantities.

Assembly - Steps 1-3

Attaching Legs and Side Panels

Connects legs to table top and attaches side panels.

Assembly - Steps 4-6

Installing Tank Support, Door, and Lid

Secures tank support, attaches door, adds fire glass/lid.

Assembly - Steps 7-8

Securing Cylinder and Installing Battery

Secures propane cylinder and installs igniter battery.

Operating Instructions

General Operating Precautions

Warns against improper use, food prep, and high temperatures.

Initial Lighting Procedure

Explains the initial burn-in process and slight odor.

Operating Instructions

Leak Testing Procedure

Step-by-step guide for checking gas leaks using a soap solution.

Operating Instructions

Lighting the Fire Pit

Detailed steps for igniting the burner using the igniter or match.

Shut Down Procedure

Instructions for turning off the burner and cylinder valve.

Maintenance

Storage Between Uses

Guidelines for storing the appliance when not in use.

Storage During Extended Inactivity

Instructions for long-term storage or transportation.

Care and Cleaning

Regular maintenance for optimal performance and longevity.

Troubleshooting

Flame and Heat Issues

Addresses low flame/heat, yellow flame, and gas smell.

Ignition Problems

Solutions for when the burner won't light with the igniter.

Operational Issues

Covers problems like the burner not staying lit or regulator humming.

PHI VILLA E02GF143 Specifications

General

Brand	PHI VILLA
Model	E02GF143
Category	Indoor Furnishing
Language	English
