Philips 105S5 - Page 8

Engineering Specification
PHILIPS Confidential – Do Not Copy 105S5
II-4
A A' BB'
C'
D
D'
Pincushion < =2mm
Barlel < =1.5mm
4.7 Linearity
4.8 Picture distortion
4.8.1 Trapezoid / Parallelogram
4.8.2 Pincushion / Barrel
4.8.3 Tilt
12*9 blocks @ factory preset size
Input singal : Cross-hatch pattern
V-Linearity :
Xmax
Xmax
Ymax
Ymax
Xmin
Ymin
Ymin
Xmin
X 100%H-Linearity :
X 100%
+
-
+
-
< 7%
< 7%
2mm 2mm
2mm
2mm
202mm
270mm
Trapezoid:
Horizontal <= 2mm
Vertical <= 2mm
Parallel <= 2mm
202mm
270mm
A
B
Bezel
