1-12-6 T6410PIN
87 IN
C-FG
Capstan Motor
Rotation Detection
Pulse
88
- AMPVss AMPVss (GND)
89 -
NU Not Used
90
IN D-PFG
Drum Motor Phase/
Frequency
Generator
91 OUT
AMP VREF-
OUT
Standard Voltage
Output
92 IN
AMP VREF-
IN
Standard Voltage
Input
93
- C C Terminal
94
IN/
OUT
CTL (-) CTL (-)
95
IN/
OUT
CTL (+) CTL (+)
96 -
AMPC AMPC
97 OUT
CTL AMP-
OUT
Control Amp Output
98
- AMPVcc AMPVcc
99
-AVcc
A/D Converter
Power Input/
Standard
Voltage Input
100
IN AGC
Tuner IF Output
Signal
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
