ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
14PV120/07 14PV125/01 14PV125/07 14PV125/39 14PV125/58 14PV225/01 14PV225/07 14PV225/39 14PV422/58 14PV225/58 14PV422/01 14PV422/07 14PV422/39
R271 CHIP RES.(1608) 1/10W J 10K OHM 1111111111111
R272 CHIP RES.(1608) 1/10W J 18K OHM 1111111111111
R273 CHIP RES.(1608) 1/10W J 18K OHM 1111111111111
R274 CHIP RES.(1608) 1/10W J 10K OHM 1111111111111
R275 CHIP RES.(1608) 1/10W J 560 OHM 1111111111111
R276 CHIP RES.(1608) 1/10W J 1.5K OHM 1111111111111
R277 CHIP RES.(1608) 1/10W J 560 OHM 1111111111111
R278 CHIP RES.(1608) 1/10W J 1.5K OHM 1111111111111
R279 CHIP RES.(1608) 1/10W J 560 OHM 1111111111111
R280 CHIP RES.(1608) 1/10W J 1.5K OHM 1111111111111
R281 CHIP RES.(1608) 1/10W J 3.3K OHM 1111111111111
R282 CARBON RES. 1/4W J 330 OHM 1111111111111
R287 CHIP RES.(1608) 1/10W J 470 OHM 1111111111111
R288 CHIP RES.(1608) 1/10W 0 OHM 1111111111111
R289 CHIP RES.(1608) 1/10W 0 OHM 1111111111111
R301 CHIP RES.(1608) 1/10W J 1.2K OHM 1111111111111
R302 CHIP RES.(1608) 1/10W J 4.7K OHM 1111111111111
R303 CHIP RES.(1608) 1/10W J 100 OHM 1111111111111
R304 CHIP RES.(1608) 1/10W J 2.7K OHM 1111111111111
R305 CHIP RES.(1608) 1/10W J 1.2K OHM 1111111111111
R306 CHIP RES.(1608) 1/10W J 100 OHM 1111111111111
R307 CHIP RES.(1608) 1/10W J 1.2K OHM 1111111111111
R308 CHIP RES.(1608) 1/10W J 100 OHM 1111111111111
R309 CHIP RES.(1608) 1/10W J 1.2K OHM 1111111111111
R310 CHIP RES.(1608) 1/10W J 1K OHM 1111111111111
R311 CARBON RES. 1/4W J 12 OHM 1111111111111
R312 CHIP RES.(1608) 1/10W J 100 OHM 1111111111111
R313 CHIP RES.(1608) 1/10W J 220K OHM 1111111111111
R314 CHIP RES.(1608) 1/10W J 4.7K OHM 1111111111111
R315 CHIP RES.(1608) 1/10W J 150K OHM 1111111111111
R316 CARBON RES. 1/4W J 15K OHM 1111111111111
R317 CARBON RES. 1/4W J 220K OHM 1111111111111
R318 CHIP RES.(1608) 1/10W J 6.8K OHM 1111111111111
R320 CHIP RES.(1608) 1/10W J 10K OHM 1111111111111
R321 CHIP RES.(1608) 1/10W J 220 OHM 1111111111111
R322 CHIP RES.(1608) 1/10W J 3.3K OHM 1111111111111
R323 CHIP RES.(1608) 1/10W J 15K OHM 1111111111111
R324 CHIP RES.(1608) 1/10W J 4.7K OHM 1111111111111
R325 CHIP RES.(1608) 1/10W J 10K OHM 1111111111111
R326 CHIP RES.(1608) 1/10W J 6.8K OHM 1111111111111
R327 PCB JUMPER D0.6-P5.0 1111111111111
R328 CHIP RES.(1608) 1/10W J 47K OHM 1111111111111
R332 CHIP RES.(1608) 1/10W J 100 OHM 1111111111111
R333 CHIP RES.(1608) 1/10W J 100 OHM 1111111111111
R334 CHIP RES.(1608) 1/10W J 100 OHM 1111111111111
R335 CARBON RES. 1/4W J 100 OHM 1111111111111
R336 CHIP RES.(1608) 1/10W J 10K OHM 1111111111111
R339 CHIP RES.(1608) 1/10W 0 OHM 1111111111111
R340 CHIP RES.(1608) 1/10W 0 OHM 1111111111111
R401 CHIP RES.(1608) 1/10W J 1.2K OHM 1111111111111
R402 CHIP RES.(1608) 1/10W J 8.2K OHM 1111111111111
R405 CHIP RES.(1608) 1/10W J 10K OHM 1111111111111
R406 CHIP RES.(1608) 1/10W J 1.2K OHM 1111111111111
R407 CHIP RES.(1608) 1/10W J 390K OHM 1111111111111
R408 CHIP RES.(1608) 1/10W J 330 OHM 1111111111111
R409 CHIP RES.(1608) 1/10W J 330 OHM 1111111111111
R410 CHIP RES.(1608) 1/10W J 220 OHM 1111111111111
R411 CHIP RES.(1608) 1/10W J 4.7K OHM 1111111111111
R412 CHIP RES.(1608) 1/10W J 4.7K OHM 1111111111111
1-14-25
