ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
14PV120/07 14PV125/01 14PV125/07 14PV125/39 14PV125/58 14PV225/01 14PV225/07 14PV225/39 14PV422/58 14PV225/58 14PV422/01 14PV422/07 14PV422/39
R744 CHIP RES.(1608) 1/10W J 47K OHM 1111111111111
R745 CHIP RES.(1608) 1/10W J 6.2K OHM 1111111111111
R746 CHIP RES.(1608) 1/10W J 47K OHM 1111111111111
R747 CHIP RES.(1608) 1/10W J 6.2K OHM 1111111111111
R748 CHIP RES.(1608) 1/10W J 1.8K OHM 1111111111111
R749 CHIP RES.(1608) 1/10W J 10K OHM 1111111111111
R750 CHIP RES.(1608) 1/10W J 2.7K OHM 1111111111111
R751 CHIP RES.(1608) 1/10W J 1.8K OHM 1111111111111
R752 CHIP RES.(1608) 1/10W J 1K OHM 1111111111111
R753 CARBON RES. 1/4W J 1.8K OHM 1111111111111
R754 CHIP RES.(1608) 1/10W J 22K OHM 1111111111111
R755 CHIP RES.(1608) 1/10W J 470 OHM 1111111111111
R756 CHIP RES.(1608) 1/10W J 1K OHM 1111111111111
R757 CHIP RES.(1608) 1/10W J 470K OHM 1111111111111
R851 CHIP RES.(1608) 1/10W J 5.6K OHM 1111111111111
R852 CHIP RES.(1608) 1/10W J 22K OHM 1111111111111
R853 CHIP RES.(1608) 1/10W J 2.2K OHM 1111111111111
R854 CHIP RES.(1608) 1/10W J 2.2K OHM 1111111111111
R856 CARBON RES. 1/4W J 47K OHM 1111111111111
R857 CARBON RES. 1/4W J 100 OHM 1111111111111
R858 CARBON RES. 1/4W J 820 OHM 1111111111111
R859 CHIP RES.(1608) 1/10W J 680 OHM 1111111111111
R860 CHIP RES.(1608) 1/10W J 22K OHM 1111111111111
R861 CHIP RES.(1608) 1/10W J 330K OHM 1111111111111
R862 CHIP RES.(1608) 1/10W J 12K OHM 1111111111111
R863 CHIP RES.(1608) 1/10W J 120 OHM 1111111111111
R864 CHIP RES.(1608) 1/10W J 560 OHM 1111111111111
R865 CHIP RES.(1608) 1/10W J 1.8K OHM 1111111111111
R866 CHIP RES.(1608) 1/10W J 12K OHM 1111111111111
R867 CHIP RES.(1608) 1/10W J 100 OHM 1111111111111
R869 CHIP RES.(1608) 1/10W J 3.3K OHM 1111111111111
R870 CHIP RES.(1608) 1/10W J 56K OHM 1111111111111
R871 CHIP RES.(1608) 1/10W J 1M OHM 1111111111111
R874 CHIP RES.(1608) 1/10W J 4.7K OHM 1111111111111
R876 CHIP RES.(1608) 1/10W J 4.7K OHM 1111111111111
R877 CHIP RES.(1608) 1/10W J 15K OHM 1111111111111
R878 CHIP RES.(1608) 1/10W J 12K OHM 1111111111111
R879 CHIP RES.(1608) 1/10W J 5.6K OHM 1111111111111
RS201 9965 000 10857 REMOTE RECEIVER PIC-37042LU 1111111111111
SW201 9965 000 14390 TACT SWITCH SKQNAED010 1111111111111
SW202 9965 000 14390 TACT SWITCH SKQNAED010 1111111111111
SW203 9965 000 14390 TACT SWITCH SKQNAED010 1111111111111
SW204 9965 000 14390 TACT SWITCH SKQNAED010 1111111111111
SW205 9965 000 14390 TACT SWITCH SKQNAED010 1111111111111
SW206 9965 000 14390 TACT SWITCH SKQNAED010 1111111111111
SW207 9965 000 14390 TACT SWITCH SKQNAED010 1111111111111
SW208 9965 000 14390 TACT SWITCH SKQNAED010 1111111111111
SW209 9965 000 14390 TACT SWITCH SKQNAED010 1111111111111
SW210 9965 000 14390 TACT SWITCH SKQNAED010 1111111111111
SW211 9965 000 12192 LEAF SWITCH MXS00052MPP0 1111111111111
SW212 9965 000 16626 ROTARY MODE SWITCH SSS-50MD 1111111111111
TB3 9965 000 18113 HEAD SHIELD S T6400RA 1111111111111
TB7 9965 000 18114 LED HOLDER T6400RA 1111111111111
TB21 9965 000 08566 BUSH, LED(F) H3700UD 1111111111111
TP001 PCB JUMPER D0.6-P12.5 1111111111111
TP002 PCB JUMPER D0.6-P12.5 1111111111111
TP003 PCB JUMPER D0.6-P12.5 1111111111111
