Philips 14PV225 - Page 39

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
14PV120/07 14PV125/01 14PV125/07 14PV125/39 14PV125/58 14PV225/01 14PV225/07 14PV225/39 14PV422/58 14PV225/58 14PV422/01 14PV422/07 14PV422/39
R638 CARBON RES. 1/4W J 39K OHM 1111111111111
R639 CARBON RES. 1/4W J 39K OHM 1111111111111
R640 CARBON RES. 1/4W J 2.7K OHM 1111111111111
R641 CARBON RES. 1/2W J 1K OHM 1111111111111
R642 CARBON RES. 1/4W J 10K OHM 1111111111111
R643 CARBON RES. 1/4W J 2.7K OHM 1111111111111
R644 CARBON RES. 1/4W J 2.7K OHM 1111111111111
R645 CARBON RES. 1/4W J 56K OHM 1111111111111
R646 CARBON RES. 1/4W J 15 OHM 1111111111111
R647 CARBON RES. 1/4W J 2.7K OHM 1111111111111
R649 CARBON RES. 1/4W J 390 OHM 1111111111111
R651 CARBON RES. 1/4W J 100 OHM 1111111111111
R652 METAL OXIDE FILM RES. 2W J 22 OHM 1111111111111
R653 CARBON RES. 1/4W J 150 OHM 1111111111111
R654 CARBON RES. 1/4W J 2.2K OHM 1111111111111
R655 CARBON RES. 1/4W J 5.6K OHM 1111111111111
R656 CARBON RES. 1/4W J 47K OHM 1111111111111
R657 CARBON RES. 1/4W J 220 OHM 1111111111111
R658 METAL OXIDE FILM RES. 2W J 10K OHM 1111111111111
R659 METAL OXIDE FILM RES. 2W J 10K OHM 1111111111111
R660 PCB JUMPER D0.6-P5.0 1111111111111
R661 CARBON RES. 1/4W J 1.8K OHM 1111111111111
R662 CARBON RES. 1/4W J 820K OHM 1111111111111
SA601
h
9965 000 13898 SURGE ABSORBER PVR-07D471KB 1111111111111
SW601
h
9965 000 13902 POWER SWITCH SDKVA30100 1111111111111
T551 9965 000 18124 FLYBACK TRANS BSC23-2603S 1111111111111
T552 9965 000 13904 H0RIZONTAL DRIVE TRANS LP2-005 1111111111111
T601
h
9965 000 18125 SWITCHING TRANS 03701 1111111111111
TM601
h
TAB 42018 1111111111111
TM602
h
TAB 42018 1111111111111
TP501 PCB JUMPER D0.6-P7.5 1111111111111
TP502 PCB JUMPER D0.6-P7.5 1111111111111
TP503 PCB JUMPER D0.6-P15.0 1111111111111
TP504 PCB JUMPER D0.6-P15.0 1111111111111
VR601 9965 000 13906 CARBON P.O.T. 10K OHM B 1111111111111
C501 CERAMIC CAP.(AX) B K 220PF/50V 1111111111111
C502 CERAMIC CAP.(AX) B K 220PF/50V 1111111111111
C503 CERAMIC CAP.(AX) B K 220PF/50V 1111111111111
C504 CERAMIC CAP. B K 1000PF/2KV 1111111111111
C505 ELECTROLYTIC CAP. 1UF/50V M H7 1111111111111
CL501A 9965 000 18126 LEAD WIRE 3P/230 1111111111111
CN501 9965 000 13911 PIN CONNECTOR 005P-5100 1111111111111
CN502 9965 000 05247 CONNECTOR BASE, 4P TUC-P04P-B1 1111111111111
JK501 9965 000 13913 CRT SOCKET ISMS01S 1111111111111
L501 PCB JUMPER D0.6-P5.0 1111111111111
Q501 4822 130 60578 TRANSISTOR 2SC2482 TPE6 1111111111111
Q502 4822 130 60578 TRANSISTOR 2SC2482 TPE6 1111111111111
Q503 4822 130 60578 TRANSISTOR 2SC2482 TPE6 1111111111111
R501 METAL OXIDE FILM RES. 1W J 18K OHM 1111111111111
R502 METAL OXIDE FILM RES. 1W J 18K OHM 1111111111111
RESISTORS
CRT CBA
CAPACITORS
CONNECTORS
TRANSISTORS
SWITCHES
TRANSISTORS
1-14-32
