ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
14PV120/07 14PV125/01 14PV125/07 14PV125/39 14PV125/58 14PV225/01 14PV225/07 14PV225/39 14PV422/58 14PV225/58 14PV422/01 14PV422/07 14PV422/39
R503 METAL OXIDE FILM RES. 1W J 18K OHM 1111111111111
R504 CARBON RES. 1/4W J 1.5K OHM 1111111111111
R505 CARBON RES. 1/4W J 1.5K OHM 1111111111111
R506 CARBON RES. 1/4W J 1.5K OHM 1111111111111
R507 CARBON RES. 1/4W J 1.5K OHM 1111111111111
R510 CARBON RES. 1/4W J 1.5K OHM 1111111111111
R511 PCB JUMPER D0.6-P5.0 1111111111111
R512 PCB JUMPER D0.6-P5.0 1111111111111
R513 PCB JUMPER D0.6-P5.0 1111111111111
R514 CARBON RES. 1/4W J 1.5K OHM 1111111111111
R515 CARBON RES. 1/4W J 120K OHM 1111111111111
R516 CARBON RES. 1/4W J 15 OHM 1111111111111
R517 CARBON RES. 1/4W J 560 OHM 1111111111111
R518 CARBON RES. 1/4W J 120K OHM 1111111111111
R519 CARBON RES. 1/4W J 15 OHM 1111111111111
R520 CARBON RES. 1/4W J 560 OHM 1111111111111
R521 CARBON RES. 1/4W J 120K OHM 1111111111111
R522 CARBON RES. 1/4W J 15 OHM 1111111111111
R523 CARBON RES. 1/4W J 560 OHM 1111111111111
C901 ELECTROLYTIC CAP. 22UF/50V M 1111111
C902 CERAMIC CAP.(AX) B K 100PF/50V 1111111
C903 ELECTROLYTIC CAP. 0.1UF/50V M 1111111
C904 ELECTROLYTIC CAP. 0.1UF/50V M 1111111
C905 CERAMIC CAP.(AX) Y M 0.01UF/16V 1111111
C906 ELECTROLYTIC CAP. 100UF/10V M 1111111
C916 CERAMIC CAP.(AX) CH J 18PF/50V 1111111
C917 CERAMIC CAP.(AX) CH J 18PF/50V 1111111
C920 CERAMIC CAP.(AX) Y M 0.01UF/16V 1111111
C921 ELECTROLYTIC CAP. 100UF/10V M 1111111
C922 ELECTROLYTIC CAP. 100UF/10V M 1111111
C923 ELECTROLYTIC CAP. 100UF/10V M 1111111
C926 CERAMIC CAP.(AX) Y M 0.01UF/16V 1111111
CN901 9965 000 13916 CONNECTOR, 8P TUC-P08X-B1 1111111
CN902 9965 000 13917 CONNECTOR, 6P TUC-P06X-B1 1111111
D901 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D902 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D903 9965 000 18140 ZENER DIODE MTZJT-773.6B 1111111
D904 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D905 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D906 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D907 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D908 9965 000 18119 ZENER DIODE DZ-3.3BSBT265 1111111
D909 9965 000 18119 ZENER DIODE DZ-3.3BSBT265 1111111
IC901 9965 000 18141 IC:TEXT SAA5265 1111111
L901 9965 000 18142 INDUCTOR 10UH-J-26T 1111111
L902 9965 000 18142 INDUCTOR 10UH-J-26T 1111111
Q901 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111
Q901 TRANSISTOR 2SC2785(H) 1111111
Q901 TRANSISTOR 2SC2785(J) 1111111
Q901 TRANSISTOR KTC3199(GR) 1111111
DIODES
IC’s
COILS
TRANSISTORS
TEXT CBA
CAPACITORS
CONNECTORS
1-14-33
