Philips 14PV225 - Page 41

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
14PV120/07 14PV125/01 14PV125/07 14PV125/39 14PV125/58 14PV225/01 14PV225/07 14PV225/39 14PV422/58 14PV225/58 14PV422/01 14PV422/07 14PV422/39
Q901 TRANSISTOR KTC3198(GR) 1111111
Q901 TRANSISTOR 2SC1815-GR(TPE2) 1111111
R901 CARBON RES. 1/4W J 2.2K OHM 1111111
R902 CARBON RES. 1/4W J 1K OHM 1111111
R903 CARBON RES. 1/4W J 24K OHM 1111111
R904 CARBON RES. 1/4W J 10K OHM 1111111
R905 CARBON RES. 1/4W J 10K OHM 1111111
R906 CARBON RES. 1/4W J 1.5K OHM 1111111
R908 CARBON RES. 1/4W J 1.5K OHM 1111111
R911 CARBON RES. 1/4W J 1.5K OHM 1111
R912 CARBON RES. 1/4W J 1K OHM 1111
R913 PCB JUMPER D0.6-P5.0 1111
R914 PCB JUMPER D0.6-P5.0 1111
R915 PCB JUMPER D0.6-P5.0 1111
R916 CARBON RES. 1/4W J 220 OHM 1111
R918 METAL OXIDE FILM RES. 2W J 56 OHM 1111
R919 PCB JUMPER D0.6-P5.0 1111
R920 PCB JUMPER D0.6-P5.0 1111
R921 CARBON RES. 1/4W J 3.3K OHM 1111
R922 CARBON RES. 1/4W J 3.3K OHM 1111
R923 CARBON RES. 1/4W J 3.3K OHM 1111
R924 CARBON RES. 1/4W J 1K OHM 1111
R925 CARBON RES. 1/4W J 10 OHM 1111
R926 CARBON RES. 1/4W J 4.7K OHM 1111
R927 CARBON RES. 1/4W J 1K OHM 1111
X901 9965 000 12194 X’TAL 12.000MHZ 1111
RESISTORS
