Philips 14PV360 - Page 72

MECHANICAL PARTS LIST
Pos. Pos. Exploded View
h
12 NC Description
14PV360/01 14PV360/39 14PV365/07 14PV365/58 14PV360/07 14PV365/01 14PV365/39
58 TL1 SHIELD PLATE SCREW M3X4 1 1 1 1111
60 B13 GROUND PLATE CRT 1 1 1 1111
61 3143 021 20071 EARTH SPRING (TU) 1 1 1 1111
1B1 DECK ASSEMBLY CZD011/VM15A6 1 1 1 1111
TB1 TRAY CHASSIS T6300RA 1 1 1 1111
TB2 TOP COVER T6300RA 1 1 1 1111
TB10 9965 000 13833 RCA HOLDER T6300RA 1 1 1 1111
TB11 CLOTH(10X30XT0.5) B5900UA 1 1 1 1111
TB23 BOTTOM PLATE T6300RA 1 1 1 1111
TL1 9965 000 08646 SCREW, P-TIGHT 3X12 WASHER HEAD+ 1 1 1 1111
TL14 9965 000 12171 SCREW, B-TIGHT M3X8 BIND HEAD+ 1 1 1 1111
PACKING
450 S1 BOX FOLDED 14PV36X 1 1 1 1111
451 TAPE S-ADH PP TP 0.038X75MM 1 1 1 1111
452 S6 PE-PLATE 1 1 1 1111
453 S2 STYROFOAM TOP A 1 1 1 1111
454 S3 STYROFOAM BOTTOM A 1 1 1 1111
455 X1 BAG (==>MAINS CORD) 1 1 1 1111
150 3143 028 50031 Remote Control RT722/111 1 1 1 1111
TEST TAPES
1 3143 023 20011
TEST TAPE FL6K(S) /
for verifying the audio frequency
response
1111111
2 3143 023 20021 TEST TAPE FL6NS8 1 1 1 1111
4 3143 023 20041
TEST TAPE FL6M /
for verifying the wow & flutter
1111111
