Philips 14PV360 - Deck Parts List

DECK PARTS LIST DECK PARTS LIST
Pos.
h
12 NC Description Pos.
h
12 NC Description
B2 9965 000 12895
CYLINDER ASS.
MK11 PAL 2HD 2SP
B516 9965 000 05342 REEL WASHER MK9 5*2.1*0.5
B3 9965 000 12202 LOADING MOTOR ASS. MK11 B518 4822 532 13159 P.S.W CUT 1.6X4.0X0.5T
B8 9965 000 12203 PULLEY ASS. MK11 B520 9965 000 12229 T BRAKE SPRING HI(F) MK11
B9 9965 000 08560 MOVING GUIDE S PREP: MK10 B521 9965 000 08482 SOFT SPRING MK10
B10 9965 000 08431 MOVING GUIDE T PREP: MK10 B522 9965 000 08483 TG POST ASS. MK10
B11 9965 000 12204 LOADING ARM T(B) ASS. MK11 B525 9965 000 12230 LDG BELT MK11
B12 9965 000 12205 LOADING ARM S(B) ASS. MK11 B529 9965 000 12231 CLEANER ASS. MK11
B27 9965 000 12206 TENSION LEVER SUB ASS. MK11 B551 9965 000 12232 FF ARM(HI) MK10
B31 9965 000 13920 AC HEAD ASS. MK11(TVCR) B553 9965 000 12233 REV SPRING MK11
B35 9965 000 12208 TAPE GUIDE ASS. MK11 B555 9965 000 12234 RACK ASS. MK11
B37 9965 000 13921 CAPSTAN MOTOR B557 9965 000 08519 MOTOR PULLEY U5
B52 9965 000 08593 CAP BELT MK10 B558 9965 000 12235 LOADING MOTOR
B73 9965 000 12210 FE HEAD ASS. MK11 B559 9965 000 12236 CLUTCH ASS.(HI)(2) MK11
B74 9965 000 08555 PRISM MK10 B560 9965 000 08522 KICK SPRING MK10
B121 9965 000 12211 WORM MK11 B561 9965 000 08523 F DOOR SPRING MK10
B126 9965 000 12212 PULLEY MK11 B562 9965 000 08524 C DRIVE LEVER L MK10
B133 9965 000 12213 IDLER ASS.(2) MK10 B563 9965 000 08525 SLIDER SHAFT MK10
B148 4822 462 11189 TG CAP MK6 B564 9965 000 12237 M GEAR(HYT) N12G5F*
B300 9965 000 12214 C DRIVE LEVER R MK11 B565 9965 000 12238 SENSOR GEAR MK11
B303 9965 000 12215 F DOOR OPENER MK11 B567 9965 000 08544 PINCH ARM(B) MK10
B347 9965 000 08445 GUIDE HOLDER A MK10 B568 9965 000 08545 BT ARM MK10
B354 9965 000 12216 SLIDER R MK11 B569 9965 000 12239 CAM HOLDER F MK11
B355 9965 000 12217 SLIDER L MK11 B570 9965 000 12240 CAM RACK SPRING(HI) MK11
B359 9965 000 12416 CLEANER LEVER MK11 B571 4822 532 13158 P.S.W F 6*2.55*0.5
B360 9965 000 06561 CLEANER ROLLER MK9 B572 4822 532 13159 P.S.W CUT 1.6X4.0X0.5T
B410 9965 000 12218 PINCH ARM(A) ASS. MK11 B573 9965 000 12241 REEL S MK11
B411 9965 000 08453 PINCH SPRING MK10 B574 9965 000 12376 REEL T MK10
B414 9965 000 12219 M BRAKE S(HI) ASS. MK11 B578 9965 000 12243 TR GEAR A MK10
B416 9965 000 12220 M BRAKE T(HI) ASS. MK11 B579 9965 000 12244 TR GEAR B MK10
B417 9965 000 12221 TENSION SPG(190265) MK11 B580 9965 000 12245 TR GEAR C MK11
B425 9965 000 08457 LOCK LEVER SPRING MK10 B581 9965 000 12246 CENTER GEAR(HYT) N12G5F*
B426 9965 000 08458 KICK PULLEY MK10 B582 9965 000 12247 TR GEAR SPRING MK10
B482 9965 000 12222 C PLATE MK11 B583 9965 000 05342 REEL WASHER MK9 5*2.1*0.5
B483 9965 000 08461 LOCK LEVER MK10 B584 9965 000 12248 TR GEAR SHAFT MK10
B487 9965 000 08462 BAND BRAKE MK10 B585 9965 000 12249 PSW(2957505) MK11
B488 9965 000 12223 MODE LEVER(HI) MK11 L1051 9965 000 05359
SCREW, B-TIGHT
M2.6X6 PAN HEAD+
B491 9965 000 12224 CAM GEAR(A) MK11 L1053 9965 000 05375
SCREW, S-TIGHT
M2.6X8 WASHER HEAD+
B492 9965 000 12225 MODE GEAR MK11 L1151 9965 000 08642
SCREW, SEMS
M2.6X4 PAN HEAD+
B494 9965 000 12226 DOOR OPENER B MK11 L1191 9965 000 05375
SCREW, S-TIGHT
M2.6X8 WASHER HEAD+
B499 9965 000 08467 T LEVER HOLDER MK10 L1321 4822 502 14009
SCREW, S-TIGHT
M3X6 BIND HEAD+
B501 9965 000 12227 WORM HOLDER MK11 L1341 4822 502 14669
SCREW, P-TIGHT
M2.6X6 BIND HEAD+
B502 9965 000 08469 CAM GEAR(B) MK10 L1406 9965 000 08643 AC HEAD SCREW MK9
B505 9965 000 12372 PSCW(625504) MK11 L1407 9965 000 12250
SCREW, S-TIGHT
M2.6X10 DISH HEAD+
B507 9965 000 05342 REEL WASHER MK9 5*2.1*0.5 L1450 4822 502 14671
SCREW, SEMS
M2.6X5 PAN HEAD+
B508 9965 000 08470 S BRAKE SPRING MK10 L1461 4822 502 30471
SCREW, P-TIGHT
M2.6X6 WASHER HEAD+
B513 9965 000 08471 PSCW(752605) MK10 L1466 9965 000 05364
SCREW, S-TIGHT
M2.6X6 BIND HEAD+
B514 9965 000 12228 SCREW RACK MK11 L1467 9965 000 12251
SCREW, S-TIGHT
M2.6X5 WASHER HEAD+
L1468 9965 000 12252
SCREW, B-TIGHT
M1.7X12
